| TEKNİK ÖZELLİK | SERBEST HAVA ÇIKIŞI | GÜÇ | BAĞLANTI | SES | ÖLÇÜLER | AĞIRLIK | ||
|---|---|---|---|---|---|---|---|---|
| MODELLER | 8 bar m³/dk | 10 bar m³/dk | 13 bar m³/dk | (KW / HP) | inch | dbA | (En-Boy-Yük.) (mm.) | (KG.) |
| TRIO-3 | 0.37 | 0.31 | 0.28 | 2.2 / 3 | 3/4″ | 67 | 550x850x900 | 180 |
| TRIO-5 | 0.54 | 0.41 | 0.32 | 4 / 5.5 | 3/4″ | 67 | 550x850x900 | 195 |
| TRIO-7 | 0.86 | 0.67 | 0.43 | 5.5 / 7.5 | 3/4″ | 69 | 550x850x900 | 205 |
| TRIO-10 | 1.2 | 0.90 | 0.70 | 7.5 / 10 | 3/4″ | 70 | 780x900x1200 | 220 |
| TRIO-15 | 1.8 | 1.4 | 1.1 | 11 / 15 | 3/4″ | 70 | 780x900x1450 | 230 |
| TRIO-20 | 2.6 | 2.1 | 1.7 | 15 / 20 | 1″ | 72 | 850x900x1450 | 335 |
| TRIO-25 | 3.1 | 2.6 | 2.1 | 18.5 / 25 | 1″ | 72 | 850x1000x1500 | 345 |
| TRIO-30 | 3.8 | 3.0 | 2.6 | 22 / 30 | 1 1/4″ | 74 | 850x1000x1500 | 495 |
| TRI0-40 | 5.2 | 4.5 | 3.6 | 30 / 40 | 1 1/4″ | 75 | 900x1120x1600 | 605 |
| TRIO-50 | 6.3 | 5.2 | 4.3 | 37 / 50 | 1 1/4″ | 76 | 900x1120x1600 | 670 |
| TRIO-60 | 7.2 | 6.2 | 5.3 | 45 / 60 | 1 1/2″ | 76 | 900x1120x1600 | 730 |
| TRIO-75 | 9.8 | 8.1 | 7.0 | 55 / 75 | 1 1/2″ | 77 | 1220x1680x1650 | 1325 |
| TRIO-100 | 12.6 | 11.3 | 9.4 | 75 / 100 | 2″ | 78 | 1220x1900x1650 | 1495 |
| TRIO-125 | 14 | 11.9 | 10.5 | 90 / 125 | 2″ | 78 | 1550x1900x1850 | 2030 |
| TRIO-150 | 19.4 | 15.5 | 13.7 | 110 / 150 | 2″ | 80 | 1550x2000x1850 | 2360 |
| TRIO-180 | 25.6 | 21 | 17.3 | 132 / 180 | 2″ | 80 | 1650x2000x1850 | 2640 |
| TRIO-220 | 28.4 | 24.4 | 20.5 | 160 / 220 | 2 2/1″ | 82 | 2000x2250x2000 | 2850 |
| TRIO-270 | 35.3 | 30.6 | 25 | 200 / 270 | 3″ | 84 | 2000x2850x2050 | 3475 |
| TRIO-340 | 43.8 | 38.7 | 32.1 | 250 / 340 | 3″ | 84 | 2000x2850x2050 | 4400 |
